Stanford CS336 Language Modeling from Scratch | Spring 2025 | Mixture of experts

Mixture of Experts (MoE) - Deep Dive

Key Concepts:

• Mixture of Experts (MoE): A sparsely activated architecture with multiple subcomponents ("experts") typically applied to the feed-forward network (FFN) layers of a transformer.
• Experts: Multiple copies or split versions of the FFN layer.
• Router: A mechanism that selects a subset of experts to process each token.
• Sparsity: The characteristic of MoE models where only a fraction of the parameters (experts) are activated during each forward pass.
• Token Choice: A routing strategy where each token selects its top-k preferred experts.
• Expert Choice: A routing strategy where each expert selects its top-k preferred tokens.
• Expert Parallelism: A parallelization strategy where each expert is placed on a separate device.
• Fine-grained Experts: Smaller experts, achieved by reducing the hidden dimension of the FFN.
• Shared Experts: Experts that are used by all tokens, regardless of the routing decision.
• Auxiliary Loss: Additional loss terms used to balance the load across experts and devices.
• Upcycling: A technique to convert a dense model into an MoE model by copying the FFN layers and adding a router.
• MLHA (Multi-Head Latent Attention): An optimization technique used in DeepSeek V3 to compress the KV cache.
• MTP (Multi-Token Prediction): A training technique used in DeepSeek V3 to predict multiple tokens in parallel.

1. Introduction to Mixture of Experts

• MoE architectures are now prevalent in high-performance language models like Grok, DeepSeek, and Llama 4.
• MoE models offer advantages over dense models in terms of performance for a given compute budget (flops).
• The term "mixture of experts" is misleading; it doesn't imply specialized experts for different domains. Instead, it refers to a sparsely activated architecture.
• The core idea is to replace the single FFN layer in a standard transformer with a router and multiple smaller or copied FFN layers (experts).

2. How Mixture of Experts Works

• In a standard transformer, the feed-forward component is a single block. In an MoE model, this block is replaced with a selector layer (router) and multiple copies of the FFN.
• The router selects a smaller number of experts for each token in each forward pass.
• If only one expert is activated and its size is the same as the dense FFN, the flops are equivalent to a dense model, but the MoE model has more parameters.
• The advantage is more parameters for memorizing facts without increasing computational cost.

3. Performance Benefits of Mixture of Experts

• Multiple papers demonstrate that MoE models outperform dense models at the same flop count.
• A paper by Fedus et al. (2022) shows that as the number of experts increases, the training loss decreases for a fixed flop count.
• AI2's Olo paper confirms this, showing that MoE models have faster training loss decay compared to dense models.
• DeepSeek V2 paper presents results showing that MoE models achieve better MMLU performance with fewer activated parameters.

4. Systems Benefits of Mixture of Experts

• MoE allows for expert parallelism, where each expert can be placed on a different device.
• The router directs tokens to the appropriate device for computation.
• This is a natural way to shard large models across multiple devices.
• Chinese groups like Quen and DeepSeek have been pioneers in open-source MoE implementations.

5. Challenges and Complexities of Mixture of Experts

• Infrastructure is complex, and the biggest advantages are realized with multi-node training.
• Routing decisions are non-differentiable, making optimization challenging.
• Training objectives require careful engineering to ensure stability.

6. Routing Mechanisms

• Token Choice: Each token selects its top-k preferred experts. This is the most common approach.
• Expert Choice: Each expert selects its top-k preferred tokens. This ensures balanced utilization of experts.
• Global Assignment: Solves a complex optimization problem to balance the mapping between experts and tokens.
• Token choice with top-k routing is the dominant approach in practice.

7. Top-K Routing in Detail

• The router computes a score for each token-expert pair, similar to an attention operation.
• The top-k experts are selected based on these scores.
• The outputs of the selected experts are combined, often using a weighted average or a simple sum.
• Surprisingly, hashing functions can also be used for routing, achieving some gains even without semantic information.
• Early attempts to use reinforcement learning (RL) for routing have been largely abandoned due to computational cost and instability.

8. Router Implementation

• The input token (residual stream) is multiplied by a learned vector for each expert to compute an affinity score.
• A softmax function normalizes these scores.
• A top-k function selects the k best experts.
• The outputs of the selected experts are weighted and summed.
• The result is added back to the original residual stream.

9. Shared and Fine-Grained Experts

• Fine-grained experts: Experts with smaller hidden dimensions, allowing for more experts without increasing the parameter count significantly.
• Shared experts: Experts that are used by all tokens, capturing shared structure in the data.
• DeepSeek pioneered the use of fine-grained and shared experts.
• Ablation studies show that fine-grained experts provide significant performance improvements.

10. Common MoE Configurations

• Early MoE models had large numbers of routed experts.
• More recent models, like DeepSeek and Quen, use a combination of fine-grained and shared experts.
• Llama 4 also uses a shared expert.
• Fine-grained experts are a common feature in modern MoE architectures.

11. Training Challenges and Techniques

• The main challenge is maintaining sparsity during training while dealing with non-differentiable routing decisions.
• Reinforcement learning (RL) has been explored but is not widely used due to computational cost.
• Stochastic approximations, such as adding noise to the router logits, have also been tried but are less common now.
• The most common approach is to use heuristic loss terms to balance the load across experts.

12. Load Balancing Losses

• The goal is to prevent a single expert from dominating the training process.
• A common loss term is the inner product between the fraction of tokens allocated to each expert and the fraction of the router probability allocated to each expert (f.p).
• This loss penalizes experts that receive a disproportionate number of tokens.
• DeepSeek uses both per-expert and per-device balancing losses.

13. DeepSeek V3's Auxiliary Loss-Free Balancing

• DeepSeek V3 introduces a novel approach where they add a fudge factor (b of i) to the softmax scores for each expert.
• This fudge factor is learned online using a simple gradient scheme, increasing the score for underutilized experts and decreasing it for overutilized experts.
• However, DeepSeek V3 still uses a complementary sequence-wise auxiliary loss to balance the load at a per-sequence level.

14. Expert and Device Parallelism

• MoE models are well-suited for expert parallelism, where each expert is placed on a separate device.
• This requires collective communication calls to route tokens to the appropriate devices and combine the outputs.
• Modern sparse matrix multiplication engines can optimize computations when multiple experts are on a single device.

15. Token Dropping

• If an expert receives too many tokens, some tokens may be dropped due to memory limitations.
• This can introduce stochasticity into the inference process, even with a temperature of zero.

16. Stability Tricks

• MoE models can be unstable and difficult to fine-tune.
• Using float32 for router computations and adding an auxiliary z-loss to the router can improve stability.
• Overfitting can be a concern when fine-tuning MoE models.
• Using a lot of data or alternating dense and MoE layers can mitigate overfitting.

17. Upcycling

• Upcycling is a technique to convert a dense model into an MoE model by copying the FFN layers and adding a router.
• This can be a cost-effective way to obtain an MoE model.

18. DeepSeek V3 Architecture Deep Dive

• DeepSeek V1 (16B parameters, 2.8B active): Uses a standard top-k routing with shared and fine-grained experts.
• DeepSeek V2 (236B parameters, 21B active): Architecture is identical to V1, but adds a device selection mechanism to reduce communication costs.
• DeepSeek V3 (671B parameters, 37B active): Uses auxiliary loss-free balancing and a sequence-wise auxiliary loss.

19. DeepSeek V3 - Multi-Head Latent Attention (MLHA)

• MLHA is an optimization technique to compress the KV cache.
• Instead of caching the full hidden state, it projects the hidden state into a lower-dimensional latent space and caches that instead.
• The projection matrices are merged with the query projection matrix to avoid extra computations.
• MLHA is not directly compatible with RoPE (Rotary Position Embeddings), requiring a workaround.

20. DeepSeek V3 - Multi-Token Prediction (MTP)

• MTP is a training technique where the model predicts multiple tokens in parallel.
• A lightweight one-layer transformer is used to predict the additional tokens.
• DeepSeek V3 only uses MTP with one token ahead.

21. Conclusion

• MoE architectures are now central to building high-performance language models.
• Discrete routing is a key challenge, but heuristic approaches seem to work well in practice.
• MoE models are cost-effective and worth learning.
