Inside Gemma 3: Modifying the output through activation hacking

Key Concepts:

• Transformer model mechanics
• Gemma 3 model
• Residual stream
• Embeddings
• Feedforward layers
• Attention blocks
• Token generation
• Neuron activation
• Gate activation
• Bias manipulation
• Premature decoding
• Model investigation
• Code switching

1. Model Setup and Configuration:

• The video focuses on exploring the internal mechanics of the Gemma 3 transformer model.
• The smallest Gemma 3 model with 1 billion parameters is used for demonstration.
• The Colab notebook available in the Gemma Cookbook is used for the experiments.
• The "Sow Configuration" allows surfacing intermediate values, specifically the residual stream and top-activated neurons in feedforward layers.
• The embedding layer, representing the initialization of the residual stream, and intermediate values before and after each attention block are enabled.

2. Initial Model Inquiry and Output:

• The model is initialized with a batch size of 1 to generate a single token for easier investigation.
• The prompt "What is the capital of Switzerland?" is used.
• The model correctly answers "Bern," acknowledging that Switzerland doesn't have an officially designated capital but Bern is the de facto capital.

3. Visualizing Intermediate Values with Premature Decoding:

• A helper function is used to perform "premature decoding" by applying the final normalization (LayerNorm) and softmax layer to the residual stream at each intermediate output.
• This allows visualizing how the model progresses through its layers.
• The visualization shows alternating patterns of attention layers (red) and feedforward layers (blue) after the initial embedding layer (green).
• The tokens in the lower layers are shifted by one, representing previously generated tokens used to initialize the residual stream.
• The model initially considers predicting Zurich or Geneva before shifting towards Bern in the final layer.

4. Investigating Top-Activated Neurons:

• The focus shifts to the final feedforward layer (layer 25) to understand why the model ultimately predicts Bern.
• The top two activated neurons in layer 25 are identified as 1937 (value around -10) and 4422 (value around -5).

5. Manipulating Neuron Activation by Adjusting Bias:

• Neuron 1937 is deactivated by adjusting the bias of the gate projection.
• Gemma 3 uses a gate activation, so a large negative bias at neuron 1937 results in a gate value of 0, effectively deactivating the neuron.
• Running the model again after deactivating neuron 1937 results in the model predicting "Zurich" as the capital of Switzerland.
• The negative activation of neuron 1937 indicates that it was suppressing something from the residual stream.

6. Analyzing Suppressed Tokens:

• The premature decoding function is applied to the value of neuron 1937 (the corresponding column in its downward prediction matrix) to check what was suppressed.
• The top 20 tokens associated with that value are examined.
• Several variations of "Swiss" and "Switzerland" are present, along with the Chinese and Russian spellings of Switzerland.
• Crucially, "Zurich" appears at position 7 and "Geneva" at position 12, indicating that suppressing them shifted the response towards Bern.
• "Argentina" is also encoded into the value of neuron 1937, potentially due to similarities in geographic landscapes between Switzerland and Argentina.

7. Boosting Neuron Activation:

• The video demonstrates that neurons can not only be deactivated but also boosted.
• Boosting a neuron too much can lead to the model outputting the same token at every step.
• The model is modified to boost neuron 1937.
• When prompted with "What is the richest country on the moon?", the modified model answers "Switzerland."
• When prompted with "What is the largest country on the moon?", the modified model answers "Argentina."

8. Conclusion:

• The video provides a glimpse into the internal mechanics of the Gemma 3 transformer model.
• It demonstrates how manipulating neuron activations can influence the model's output.
• The presenter encourages further experimentation with the Gemma 3 model and the provided Colab notebook to discover other interesting patterns and potential applications.
• Other interesting aspects of the model, such as code switching and the attention mechanism, are mentioned as areas for further exploration.
