I trained a Sign Language Detection Transformer (here's how you can do it too!)

Key Concepts

• Object Detection: Identifying and locating objects within an image or video.
• Sign Language Detection: Specifically, detecting and classifying different sign language signs.
• DETR (DEtection TRansformer): A deep learning architecture for object detection that uses transformers.
• DR Architecture: A simplified training algorithm used with DETR.
• Real-time Detection: Processing and displaying object detections in real-time.
• Pre-trained Weights: Pre-existing model weights from a previous training run, used to accelerate and improve new training.
• Fine-tuning: Adjusting a pre-trained model with new data to improve performance on a specific task.
• YOLO (You Only Look Once): A popular object detection algorithm and a specific data format for bounding box annotations.
• Label Studio: A tool for labeling images and creating training data for machine learning models.
• Hungarian Matcher (Linear Sum Assignment): An algorithm used in DETR to match predicted object queries to ground truth objects.
• Loss Function: A function that quantifies the difference between predicted and actual values, used to guide model training.
• Backbone Layer: The foundational convolutional neural network (CNN) used for feature extraction in the DETR model (e.g., ResNet50).
• Transformer: A neural network architecture that uses self-attention mechanisms to process sequential data.
• Inference Time: The time it takes for a model to make a prediction on a single input.
• Frames Per Second (FPS): The number of frames processed per second, a measure of real-time performance.
• UV: A python package and environment manager.
• Naughty: The name of the custom library created for this project.

1. Setting up Real-time Detection with Pre-trained Weights

• Cloning the GitHub Repository: The first step involves cloning the provided GitHub repository containing the code and pre-trained weights using the command git clone <repository_link>.
• Navigating to the Directory: After cloning, the user navigates into the cloned directory using cd sign-detr.
• Opening in VS Code: The project is then opened in VS Code using the command code ..
• File Structure Overview: The repository contains:
  • data/pre-train: Images and labeled data.
  • Checkpoints: Pre-trained model weights (trained for 4426 epochs in approximately 24 hours on a MacBook).
  • source: Contains the core code, including realtime.py, data.py, model.py, train.py, test.py, and utils.
• Running Real-time Detection: The realtime.py file is executed using uv run source realtime.py. This requires UV to be installed (pip install uv).
• Camera Device Selection: The realtime.py script allows specifying the camera device to use (default is device 0).
• Logging Information: The script provides logging information, including:
  • Model name.
  • Number of classes.
  • Hidden dimensions.
  • Inference time.
  • Frames per second (FPS).
• Demonstration: The video demonstrates real-time detection of three sign language signs: "Hello," "I Love You," and "Thank You."

2. Data Collection and Preparation

• Motivation for Custom Data: The pre-trained model may not perform optimally under different lighting conditions or for different individuals, necessitating fine-tuning with custom data.
• Data Folder Structure: The data folder contains train and test subfolders, each with images and labels subfolders.
• YOLO Label Format: The labels are stored in YOLO format, with each line representing an object and containing the class ID, center coordinates (x, y), width, and height.
• Collecting Images: A utility script (utils/collect_images.py) is used to capture images from the camera.
  • The script allows specifying the camera device and the number of images to capture per class.
  • The captured images are saved into the train or test folders.
• Deleting Existing Data: The existing images and labels in the train and test folders are deleted before collecting new data.
• Labeling Images with Label Studio:
  • Label Studio is used to annotate the images with bounding boxes.
  • Label Studio is started using uv run label-studio.
  • A new project is created in Label Studio, and the images are imported.
  • The "Object Detection with Bounding Boxes" template is selected.
  • Custom labels are added, matching the order in the config.py file: "Hello," "I Love You," and "Thank You."
  • The images are then manually labeled by drawing bounding boxes around the signs and assigning the appropriate class.
• Exporting Labeled Data: The labeled data is exported from Label Studio in YOLO format with images.
• Replacing Existing Data with Labeled Data: The exported images and labels are copied into the train and test folders, replacing the original files.
• Data Validation: The data.py script can be run (uv run source data.py) to visualize the data and transformations applied during training. The train=False argument can be used to disable training augmentations and view the raw data.

3. Model Training

• Model Architecture (model.py):
  • The model uses a DETR architecture with a ResNet50 backbone for feature extraction.
  • Positional embeddings are added to the extracted features.
  • The features are then passed through a transformer encoder and decoder.
  • Two prediction heads are used: one for classification and one for bounding box regression.
  • The model architecture can be visualized using uv run source model.py, which uses the torchinfo library to display the model's layers and parameters (approximately 26.9 million trainable parameters).
• Loss Function (Hungarian Matcher):
  • The loss function uses the Hungarian matcher (linear sum assignment) to match predicted object queries to ground truth objects.
  • The loss is composed of three components:
    • Classification loss (cross-entropy loss).
    • Bounding box loss (L1 loss for coordinates).
    • Generalized Intersection over Union (GIoU) loss (area overlap).
• Training Script (train.py):
  • The train.py script contains the training loop and configuration options.
  • Pre-trained weights can be loaded to accelerate training.
  • The learning rate and loss component weights can be adjusted.
  • The number of training epochs can be set.
  • The script saves checkpoints every 10 epochs.
• Starting Training: The training process is started using the command uv run source train.py.
• Logging: The training script provides detailed logging information, including:
  • Data set statistics.
  • Data transforms.
  • Model architecture.
  • Training progress (epoch, train loss, test loss, elapsed time).
• Checkpoints: Model checkpoints are saved in the checkpoints folder.

4. Model Testing and Evaluation

• Testing Script (test.py):
  • The test.py script is used to evaluate the trained model on the test data set.
  • The path to the model weights must be specified in the script.
  • The script loads an image from the test partition, makes a prediction, and displays the results.
  • The script prints the predicted class, confidence score, and bounding box coordinates.
• Real-time Testing (realtime.py):
  • The realtime.py script is used to perform real-time object detection with the trained model.
  • The path to the model weights must be specified in the script.
  • The script captures video from the camera, makes predictions on each frame, and displays the results.
  • A confidence threshold can be set to filter out low-confidence predictions.
• Running Testing: The test script is executed using uv run source test.py and the real-time script is executed using uv run source realtime.py.
• Confidence Threshold: The confidence threshold for displaying predictions can be adjusted in the realtime.py script.

5. Conclusion

The video provides a comprehensive guide to training a sign language object detection model from scratch using the DETR architecture. It covers data collection, labeling, model training, and testing, with a focus on practical implementation and ease of use. The use of pre-trained weights, custom data, and detailed logging makes it possible to train a reasonably accurate model in a relatively short amount of time, even without a dedicated GPU. The "Naughty" library and the detailed explanations aim to simplify the process and make it accessible to a wider audience.
